Short oil alkyd resin AS-381 AR 60
Product Describtion
Short oil alkyd resin
Short oil alkyd resin based on soybean fatty acid, glycerin and penthaerithrol alcohol.
 Technical information
Characteristics
Range
Unit
Ref. Standard
Oil Length
35±1
%
ASTM D1398
Phthalic Anhydride Content
43±1
%
ASTM D563
Percent Solid 60±1 %
ASTM D1259-A
Color
Max:5 Gardener
ASTM D1544
Viscosity (D4/20°C/40 %XY) 30 - 35 ASTM D5125
Acid Value
4- 7 mg KOH/g solid
ASTM D1639
 Application
The resin is used to manufacture alkyd amine heat resistant paint.
 Solubility
  White Spirit:Insoluble
Butyl Acetate: Soluble
      Aromatic Solvents: Soluble Alcohols: Needs to be tested
  MEK: Soluble


 Specifications
  •  Fast drying
  • Enhanced abrasion resistance
  •  Improved brightness
  • Enhanced yellowing resistance
  • Improved hardness properties

 Miscibility
  • Long oil Alkyd resin: Immiscible
  • Short oil Alkyd resin: Miscible
  • Medium oil Alkyd resin: Miscible
  • Nitrocellulose: Miscible
  •  Maleic resin: Miscible
  •  Amino resin: Miscible

 Storage
Keep way from direct sunlight and between 5-40 ᵒC.
 Stability
Under aforementioned conditions: 9 months from production date.
