Short oil alkyd resin AS-380 AR 60
Product Describtion
Short oil alkyd resin
Short oil alkyd resin based on soybean fatty acid and glycerin.
 Technical information
Characteristics
Range
Unit
Ref. Standard
Oil Length
35±1
%
ASTM D1398
Phthalic Anhydride Content
43±1
%
ASTM D563
Percent Solid 60±1 %
ASTM D1259-A
Color
Max:5 Gardener
ASTM D1544
Viscosity (D4/20°C/40 %XY) 50 - 80  ASTM D5125
Acid Value
Max:10 mg KOH/g solid
ASTM D1639
 Application
The resin is used to manufacture alkyd amine heat resistant paint.
 Solubility
  White Spirit:Insoluble
Butyl Acetate: Soluble
      Aromatic Solvents: Soluble Alcohols: Needs to be tested

 Specifications
  •  Fast drying
  • Enhanced abrasion resistance
  •  Improved brightness
  • Enhanced yellowing resistance
  • Improved hardness properties


 Miscibility
  • Long oil Alkyd resin: Immiscible
  • Short oil Alkyd resin: Miscible
  • Medium oil Alkyd resin: Miscible
  • Nitrocellulose: Miscible
  •  Maleic resin: Miscible
  •  Amino resin: Miscible

 Storage
Keep way from direct sunlight and between 5-40 ᵒC.
 Stability
Under aforementioned conditions: 9 months from production date.
