UV curing Unsaturated Polyester Resin UP-1000
Product Describtion
UV curing Unsaturated Polyester Resin
UP- 1000 is an unsaturated polyester resin based on medium viscosity orthophthalic acid. This resin is designed for UV curing applications and forms a non- tacky surface with outstanding hardness properties.
 Technical information
Characteristics
Range/ Value
Unit
Ref. Standard
Solvent
Styrene


Appearance
Viscose liquid


Color
Light yellow


Percent solids
65±2
%
ISO 3251
Viscosity
200-500
cp
ISO 2555
Density
1.13±0.5
g/cm3
ISO 1675
Acid Value
Max: 25
mg KOH/g
ISO 2114

 Application
This product is recommended for production of UV lamp resin curing coatings such as Stone adhesives, fiberglass insulation.
 Cured resin characteristics
Characteristics
Range/ Value
Unit
Ref. Standard
Tensile strength
60 - 70
MPa
ISO 527
Young’s Modulus
3 - 4
GPa
ISO 527
Elongation at break
2 -3
%
ISO 527
HDT
75
ᵒC
ISO 75
Hardness
Min: 40
Barkoll
ASTM D 2583
 Storage
Keep way from direct sunlight and under 25 ᵒC.
 Stability
Under aforementioned conditions: 4 months from production date.
